Buying 358 Fence from China can give contractors, distributors, and project buyers access to customized panel sizes, posts, gates, coatings, and complete perimeter systems.
However, a quotation that simply says “358 Security Fence” does not define the product clearly enough.
Wire diameter, panel height, post wall thickness, fixing system, coating, gates, packing, and shipping can all change the final cost and the fence system you receive.
Therefore, international buyers should compare complete specifications rather than panel prices alone.
This guide explains what to confirm before ordering 358 Fence from a Chinese manufacturer.
1. Start with the 358 Mesh Specification
The name “358” traditionally refers to a welded mesh configuration of approximately 3 inches × 0.5 inch with an 8-gauge wire reference.
A common metric configuration is approximately:
- Mesh opening: 76.2 × 12.7 mm
- Wire diameter: around 4.0 mm
However, project specifications can vary. Therefore, do not rely on the product name alone.
Your RFQ should state the required mesh opening and actual wire diameter in millimeters.
2. Confirm the Actual Wire Diameter
Wire diameter affects panel weight, rigidity, steel consumption, shipping weight, and price.
Buyers may encounter 358-style welded mesh panels using different wire diameters depending on the project.
For this reason, your quotation should clearly show:
- Actual wire diameter
- Mesh opening
- Panel width
- Panel height
If two suppliers quote different wire diameters, their prices should not be compared as if the products were identical.
3. Select Panel Height by Security Requirement
358 Fence is used for commercial, industrial, utility, data center, transport, restricted-access, and other security perimeter applications.
Common project heights may include:
| Fence Height | Typical Project Direction |
|---|---|
| 1.8–2.0 m | Controlled commercial and industrial perimeter |
| 2.1–2.4 m | Industrial, utility and higher-security sites |
| 2.7–3.0 m | Restricted and high-security perimeter applications |
| Above 3.0 m | Project-specific security design |
These are selection directions rather than universal requirements. Final height should follow the project specification and applicable local requirements.
4. Taller Panels Need a Matching Post System
A common purchasing mistake is upgrading the panel while leaving the supporting post unchanged.
As fence height and panel weight increase, buyers should review:
- Post section
- Post wall thickness
- Post length
- Post spacing
- Fixing quantity
- Foundation method
- Gate-post requirements
A 3m security fence should be evaluated as a complete system rather than simply a taller 2m panel.
5. Compare Post Wall Thickness, Not Just Post Size
Two quotations may both specify the same outside post dimensions but use different wall thicknesses.
That changes the amount of steel in the post.
Therefore, ask suppliers to show both:
- Post outside dimensions
- Post wall thickness
Also confirm whether posts will be embedded into concrete or supplied with base plates for mounting onto an existing structure.
6. Check the Panel-to-Post Fixing System
The security characteristics of a 358 perimeter depend on more than the mesh panel.
The connection between panel and post also matters.
Depending on the fence design, the system may use:
- Clamp bars
- Steel fixing plates
- Security bolts
- Anti-tamper fasteners
- Other project-specific connections
When comparing quotations, confirm the fixing type and quantity supplied for each panel or post.
7. Decide Whether Top Security Is Required
Some 358 Fence projects use the welded panel alone, while others add a top-security system.
Possible options can include:
- Extended fence panels
- Security extensions
- Barbed wire
- Razor wire where legally permitted and specified
- Other project-designed deterrent systems
Top security should be treated as a separate part of the fence design.
It can affect post height, brackets, foundations, installation, packing, and overall project cost.
8. Choose the Surface Treatment for the Environment
358 Fence can be supplied with different corrosion-protection and finishing systems.
Typical project directions include:
- Galvanized finish
- Powder-coated finish
- Galvanized + powder-coated finish
The correct system depends on the installation environment, appearance requirements, maintenance plan, and project specification.
9. Coastal Projects Need Complete-System Corrosion Protection
For coastal, humid, or aggressive industrial environments, do not evaluate the panel coating alone.
Review the corrosion-protection specification for:
- 358 panels
- Line posts
- Corner and end posts
- Gate posts
- Gate frames
- Fixing plates
- Fasteners
- Top-security components
Otherwise, a well-protected mesh panel may be installed with components that have a different corrosion-protection level.
10. Include Gates in the Original RFQ
Gates should not be added after the fence quotation has already been finalized.
A 358 Fence project may require:
- Pedestrian gates
- Single swing gates
- Double swing vehicle gates
- Sliding gates
- Other controlled-access entrances
For each gate, provide the clear opening, height, gate type, and any hardware or automation requirements.
11. Gate Posts Need Separate Attention
A gate post supports a moving steel structure, while a normal line post supports fixed fence panels.
Therefore, wide or heavy security gates may require a different post specification.
A complete gate quotation should identify:
- Gate frame size
- Frame wall thickness
- 358 mesh infill
- Gate-post size
- Gate-post wall thickness
- Hinges or sliding components
- Locking hardware
12. Ask What Is Included in One Meter of Fence
Price per meter can be misleading when suppliers calculate it differently.
Ask each supplier to define whether the quotation includes:
| Component | Check Before Comparing |
|---|---|
| 358 Panels | Wire, mesh, height and width |
| Posts | Section, wall thickness and spacing |
| Fixings | Type and quantity |
| Surface Treatment | Exact finish |
| Top Security | Included or excluded |
| Gates | Usually calculated separately |
| Packing | Export packing method |
This makes supplier quotations much easier to compare.
13. Export Packing Matters for 358 Panels
358 Fence panels are rigid welded products, so export packing should protect their shape and surface finish during handling and sea transport.
A shipment may contain:
- Welded mesh panel stacks
- Post bundles
- Gate frames
- Fixing packages
- Top-security components
These products have different dimensions and should not simply be packed as one mixed group.
14. Panel Stacks Need Stable Packing
For bulk shipments, panels are normally grouped into stable packages suitable for loading and unloading.
The packing plan should consider:
- Panel dimensions
- Panel weight
- Coating protection
- Package stability
- Forklift handling
- Container dimensions
For coated panels, contact points should also be considered to reduce unnecessary surface damage during transport.
15. Posts and Fixings Should Be Easy to Identify
Large projects may contain several post types and many small fixing components.
For example:
- Line posts
- Corner posts
- End posts
- Gate posts
- Fixing plates
- Security bolts
- Post caps
Separate bundling and package identification can make site receiving and installation more efficient.
16. Container Loading Depends on More Than Fence Length
There is no universal answer to “How many meters of 358 Fence fit in one container?”
Container capacity changes according to:
- Panel height
- Panel width
- Wire diameter
- Post specification
- Gate quantity
- Top-security components
- Packing dimensions
- Total cargo weight
Therefore, container quantity should be calculated after the fence specification and BOQ are confirmed.
17. Heavy-Duty Specifications Increase Shipping Weight
Moving from a lighter panel to a heavier wire specification can increase total steel weight significantly across a large perimeter.
Taller or heavier fences may also require larger posts.
As a result, the change affects not only factory price but also:
- Packing weight
- Container payload
- Container quantity
- Ocean freight
- Site unloading
For international projects, compare the complete delivered system rather than the panel price alone.
18. Confirm the Shipping Term
Chinese manufacturers may quote using terms such as:
- EXW
- FOB
- CFR
- CIF
These terms do not include the same responsibilities or costs.
Therefore, compare suppliers using the same trade term and named port whenever possible.
19. Provide the Destination Port Early
If you want a freight-inclusive quotation, provide the destination country and port during the RFQ stage.
The supplier can then review:
- Estimated container quantity
- Cargo weight
- Packing plan
- Ocean freight basis
Destination-side customs, duties, taxes, and local charges should be checked separately according to the applicable trade arrangement.
20. Ask for Pre-Shipment Inspection Records
Before loading, buyers can request inspection information based on the agreed purchase specification.
Important checks may include:
- Wire diameter
- Mesh opening
- Panel dimensions
- Post dimensions
- Post wall thickness
- Gate dimensions
- Fixing quantity
- Visible surface condition
- Packing quantity
For large or technically sensitive projects, buyers may also arrange an independent third-party inspection.
21. Production and Loading Photos Improve Communication
International buyers may not be able to visit the factory for every shipment.
Therefore, production and loading records can help confirm order progress.
Useful records may include:
- Wire measurement
- Mesh measurement
- Panel dimensions
- Post dimensions
- Gate fabrication
- Surface finish
- Packing
- Container loading
These records complement, but do not replace, any formal inspection required by the contract.
22. Check the Supplier as Well as the Product
A good 358 Fence quotation is only part of the purchasing decision.
Buyers should also evaluate whether the supplier can support the complete order.
A practical supplier checklist can include:
- Is the supplier a manufacturer or trading company?
- Can it provide factory information?
- Does it understand 358 mesh specifications?
- Can it manufacture matching posts?
- Can it supply security fixings?
- Can it fabricate pedestrian and vehicle gates?
- Can it support customized panel heights?
- Can it provide export packing?
- Can it prepare container-loading plans?
- Can it provide inspection records?
- Can it support repeat project orders?
23. Do Not Choose a Supplier by Panel Price Alone
A lower panel price may result from a different specification rather than better purchasing value.
Possible differences include:
- Thinner wire
- Lighter posts
- Thinner post walls
- Different fixing quantities
- Different coating systems
- Excluded gates
- Excluded top security
- Different packing standards
First align the technical scope. Then compare commercial terms.
24. Build a Clear 358 Fence RFQ
For an accurate quotation, provide as much of the following information as possible:
- Project country
- Project application
- Total perimeter length
- Fence height
- Panel width
- Mesh opening
- Wire diameter
- Post section
- Post wall thickness
- Post spacing
- Embedded or base-plated installation
- Surface treatment
- RAL color if required
- Top-security requirement
- Pedestrian gate schedule
- Vehicle gate schedule
- Required fixing system
- BOQ or perimeter drawing
- Trade term
- Destination port
25. What If You Do Not Have a Complete Specification?
Some buyers start sourcing before the final BOQ is available.
In that situation, provide the information you already have, such as:
- Site application
- Country
- Approximate perimeter
- Required fence height
- Security level
- Gate requirements
- Installation environment
A manufacturer can then review the available information and identify which specifications still need confirmation before the final quotation.
BDFENCE 358 Fence Supply
Hebei Bendin Industrial Technology Co., Ltd. (BDFENCE) manufactures 358 Fence systems for commercial, industrial, utility, data center, infrastructure, restricted-access, and high-security perimeter projects.
BDFENCE project supply can include:
- 358 welded mesh panels
- Customized panel heights
- Different wire diameters
- Steel fence posts
- Corner and end posts
- Security fixing systems
- Pedestrian gates
- Vehicle gates
- Gate posts
- Top-security components
- Galvanized finishes
- Powder-coated finishes
- Galvanized + powder-coated systems
- Export packing
- Container-loading support
BDFENCE has more than 30 years of metal fence manufacturing experience, with a 15,000㎡ factory, 190+ employees, and 80+ production machines.
Our fence products have been exported to more than 70 countries.
Final Supplier Checklist Before You Place the Order
| Check | Confirmed? |
|---|---|
| Mesh opening | □ |
| Actual wire diameter | □ |
| Panel height and width | □ |
| Post size and wall thickness | □ |
| Post spacing | □ |
| Fixing system | □ |
| Surface treatment | □ |
| Top security | □ |
| Pedestrian gates | □ |
| Vehicle gates | □ |
| Export packing | □ |
| Container-loading plan | □ |
| Inspection requirements | □ |
| Trade term | □ |
| Destination port | □ |
A reliable 358 Fence purchase from China starts with a clearly defined system, not simply a request for the lowest price per panel.
Once the panel, posts, fixings, gates, coating, packing, and shipping scope are aligned, buyers can compare suppliers on a much more meaningful basis.
Contact BDFENCE
Hebei Bendin Industrial Technology Co., Ltd. (BDFENCE)
Phone:
+86 18703182863
WhatsApp:
+86 18703287372
Email:
info@bd-fence.com
Website:
https://bd-fence.com/
FAQ
What specifications should I confirm when buying 358 Fence from China?
Confirm the mesh opening, actual wire diameter, panel dimensions, post size, post wall thickness, post spacing, fixing system, coating, gates, and any top-security requirements.
What is the standard mesh size of 358 Fence?
358 Fence traditionally refers to approximately 3 × 0.5 inch mesh. A commonly used metric configuration is approximately 76.2 × 12.7 mm, although final project specifications can vary.
Is 4mm wire common for 358 Fence?
A configuration around 4.0mm wire is commonly associated with 358 welded mesh, but buyers should always confirm the actual wire diameter required by the project rather than relying only on the product name.
Can BDFENCE supply posts and security fixings with 358 panels?
Yes. BDFENCE can supply panels, posts, security fixings, gates, gate posts, and other perimeter components according to the confirmed project specification.
Can 358 Fence be galvanized and powder coated?
Yes. Different surface-treatment systems can be supplied according to the required environment, appearance, and project specification.
How many 358 Fence panels fit in a container?
Container capacity depends on panel height, width, wire diameter, post specification, gates, packing method, and total cargo weight. The loading quantity should be calculated after the BOQ is confirmed.
What information does BDFENCE need for a shipping quotation?
Provide the product specification, total quantities, gate requirements, trade term, destination country, and destination port. A BOQ or perimeter drawing is especially useful for larger projects.
Can BDFENCE support third-party inspection?
Inspection requirements can be coordinated according to the agreed order and inspection scope. Buyers may also arrange independent inspection when required by their purchasing process.
