Australia has strict requirements for perimeter security in industrial parks, particularly regarding product durability, corrosion resistance, and long-term maintenance costs. In 2025, Hebei Bendin Industrial Technology Co., Ltd. (BDFENCE) supplied a complete steel tubular fencing system for a newly developed industrial park in Melbourne, Australia.
The project required a modern fencing solution that could provide reliable security while maintaining an attractive appearance suitable for commercial tenants.
Project Overview
Item Details
Project Location Melbourne, Australia
Application Industrial Park
Product Steel Tubular Fence
Total Quantity 4,860 Fence Panels
Fence Length Approximately 9,720 meters
Posts 5,020 pcs
Pedestrian Gates 24 sets
Sliding Gates 8 sets
Surface Finish Hot-Dip Galvanized + Polyester Powder Coating
Color RAL 9005 Black
Production Time 28 Days
Shipment 10 × 40HQ Containers
Project Requirements
The client requested a fencing system that could meet three primary objectives:
Secure the entire industrial park perimeter.
Maintain an attractive architectural appearance.
Reduce maintenance costs over a service life exceeding 20 years.
Because the site is located near coastal areas of Victoria, corrosion resistance was considered one of the most important technical requirements.
Engineering Challenges
Large Project Area
The industrial park covered multiple warehouse blocks with several vehicle entrances, requiring long continuous fence lines and consistent installation quality.
Corrosion Protection
Australia’s climate exposes outdoor steel structures to strong UV radiation, rain, and coastal moisture.
The fencing system needed superior corrosion protection without frequent repainting.
Fast Construction Schedule
The developer planned to complete infrastructure before tenant occupancy, leaving a limited installation window.
Production and shipping schedules had to be carefully coordinated.
BDFENCE Solution
BDFENCE recommended a heavy-duty steel tubular fence system combining structural strength with architectural aesthetics.
The solution included:
Fully welded tubular fence panels
Heavy-duty square steel posts
Hot-dip galvanized steel components
Polyester powder coating
Matching pedestrian gates
Heavy-duty sliding vehicle gates
This configuration provided both long-term durability and an attractive commercial appearance.
Technical Specifications
Fence Panels
Specification Value
Panel Height 2100 mm
Panel Width 2400 mm
Vertical Tubes 25 × 25 × 1.5 mm
Horizontal Rails 40 × 40 × 2.0 mm
Rail Quantity 2
Fence Posts
65 × 65 × 2.5 mm Square Steel Posts
Steel Base Plates
Chemical Anchor Bolts
Decorative Post Caps
Surface Treatment
All steel components were:
Hot-Dip Galvanized
Zinc Protected
Polyester Powder Coated
UV Resistant
Corrosion Resistant
Expected service life exceeded 20 years under normal outdoor conditions.
Manufacturing Process
Production was completed in BDFENCE’s manufacturing facility using automated equipment.
The process included:
CNC tube cutting
Automatic punching
Robotic welding
Weld polishing
Surface cleaning
Hot-dip galvanizing
Powder coating
Final quality inspection
Every production stage was monitored to ensure dimensional accuracy and coating consistency.
Quality Inspection
Before shipment, all products underwent comprehensive inspections.
Inspection items included:
Tube dimensions
Welding strength
Coating thickness
Color consistency
Panel flatness
Gate operation
Packaging integrity
Random sampling inspections were also performed before container loading.
Packaging and Shipping
To prevent transportation damage during the sea voyage from China to Australia, BDFENCE applied export-standard packaging.
Each package included:
Steel pallets
Plastic protective film
Corner protection
Steel straps
Product labels
The entire order was loaded into ten 40HQ containers.
Container loading plans maximized shipping efficiency while minimizing freight costs.
Installation
Installation was completed by the client’s local contractor under BDFENCE’s technical guidance.
The project required approximately 22 working days.
The modular fence design reduced installation time and ensured consistent panel alignment throughout the industrial park.
Project Results
After completion, the steel tubular fence system successfully achieved the client’s objectives.
The customer reported several advantages:
Professional appearance
Excellent structural stability
Smooth gate operation
High corrosion resistance
Fast installation
Low maintenance requirements
The project has continued operating successfully under Australia’s outdoor environmental conditions.
Why Choose BDFENCE?
Hebei Bendin Industrial Technology Co., Ltd. specializes in manufacturing premium steel tubular fencing for commercial and industrial projects worldwide.
Our advantages include:
30+ years of manufacturing experience
15,000㎡ production facility
190+ experienced employees
80+ advanced production machines
ISO 9001 certified
CE certified
Exported to more than 70 countries
Complete OEM & ODM services
Whether your project requires standard fencing or customized perimeter security solutions, BDFENCE provides professional engineering support from design to delivery.
FAQ
Why was steel tubular fencing selected for this industrial park?
It combines strong security performance, modern appearance, and long service life while requiring minimal maintenance.
How long did production take?
Manufacturing was completed within 28 days before shipment.
What surface treatment was used?
The project used hot-dip galvanizing followed by polyester powder coating for maximum corrosion resistance.
Can BDFENCE customize steel tubular fence projects?
Yes. We manufacture customized fencing systems based on project drawings, security requirements, and local standards.
