6,400 Meters of Steel Tubular Fence Supplied for an Australia Logistics Park

Project Introduction

A property developer in Australia required a durable perimeter fence for a newly constructed logistics and distribution park. The site included warehouses, loading areas, truck entrances, employee parking spaces, utility zones, and landscaped boundaries.

The customer wanted a fence that could provide reliable access control without creating the closed appearance of solid wall fencing. The perimeter system also needed to match the modern architectural style of the industrial buildings.

After reviewing several options, the developer selected a steel tubular fence because its vertical rail structure offered a suitable combination of security, visibility, strength, and appearance.

BDFENCE was responsible for manufacturing the fence panels, posts, gates, brackets, bolts, and related installation accessories according to the approved project drawings.

Project Overview

Products Supplied

The complete order included:

• 2,668 steel tubular fence panels
• 2,745 square steel posts
• 12 double-leaf vehicle gates
• 6 sliding vehicle gates
• 28 pedestrian gates
• 5,336 panel bracket sets
• Security bolts and fixing accessories
• Spare panels, posts, and hardware for future maintenance

The products were manufactured as a complete coordinated system so that the panel dimensions, post spacing, gate heights, and fixing positions remained consistent across the entire project.

Project Challenges

Several Functional Areas Required Different Fence Configurations

The logistics park was divided into warehouse yards, truck circulation routes, public parking areas, utility zones, and restricted loading sections.

Although the same general fence style was required throughout the site, different areas needed different configurations. Some boundaries required standard panels, while entrances and high-traffic zones required reinforced posts and larger gates.

BDFENCE reviewed the fence layout and divided the production plan according to each installation zone.

Frequent Heavy-Vehicle Movement

The main entrances were designed for delivery trucks, trailers, and container vehicles.

Large gates needed sufficient opening width and structural stability for repeated daily operation. The customer also required gate frames that would remain aligned after long-term use.

For this reason, the vehicle gates were produced with reinforced frames, heavy-duty hinges, and larger supporting posts.

Architectural Consistency

The developer required the perimeter fence to complement the warehouse façades and landscaping.

Panel spacing, rail alignment, weld appearance, coating color, and gate design all needed to remain visually consistent. Variations between different production batches were not acceptable.

Long-Distance Export Transportation

The panels and gates needed to be transported from China to Australia without coating damage, deformation, or missing accessories.

The packing system therefore had to provide both surface protection and efficient container loading.

BDFENCE Solution

Uniform Tubular Panel Design

BDFENCE manufactured the main fence panels with a 2100 mm height and 2400 mm width.

The vertical rails were spaced to provide perimeter security while maintaining visibility through the fence. Horizontal rails were positioned to support the vertical members and maintain panel rigidity.

The design created a clean and consistent appearance suitable for a modern commercial development.

Reinforced Posts for Gate and Corner Locations

Standard fence lines used square steel posts matched to the panel dimensions.

Heavier post sections were produced for:

• Vehicle gate openings
• Sliding gate support points
• Fence corners
• Fence termination points
• Areas with higher structural loads

This prevented the use of an unnecessarily heavy post across the entire project while ensuring stronger support where it was required.

Customized Gate Systems

The project required three main gate categories.

Double-Leaf Vehicle Gates

Double-leaf swing gates were installed at secondary truck entrances and service areas.

Each gate included:

• Reinforced welded frame
• Matching vertical tubular infill
• Heavy-duty hinge assemblies
• Ground stops
• Locking components

Sliding Vehicle Gates

Sliding gates were selected for the primary entrances where swing space was limited.

The gate structures were designed to support future access-control equipment supplied by the customer.

Pedestrian Gates

Pedestrian gates were installed near office entrances, employee parking areas, and warehouse access routes.

Their height, rail arrangement, and powder-coated finish matched the adjacent fence panels.

Technical Specifications

Manufacturing Process

Raw Material Preparation

Steel tubes were inspected before cutting and fabrication.

The inspection focused on:

• Tube dimensions
• Wall thickness
• Surface condition
• Straightness
• Galvanized layer consistency

Only materials matching the confirmed production requirements were released to the workshop.

Tube Cutting and Positioning

Vertical and horizontal tubes were cut according to the approved panel drawings.

Positioning fixtures were used to control:

• Panel width
• Panel height
• Vertical rail spacing
• Horizontal rail position
• Frame squareness

This helped maintain consistent dimensions during batch production.

Welding and Surface Preparation

The tubular members were welded into complete panels and gate frames.

After welding, the products were checked for sharp edges, welding spatter, deformation, and incomplete joints. Surface preparation was completed before powder coating to improve coating adhesion and appearance.

Powder Coating

Panels, posts, gates, and brackets were powder-coated in a uniform black finish.

The production team controlled the coating process to reduce visible differences between components manufactured at different times.

Quality Control

Dimensional Inspection

Randomly selected panels were measured during production.

The inspection included:

• Overall panel width
• Overall panel height
• Diagonal dimensions
• Vertical rail spacing
• Bracket position

Welding Inspection

Welded joints were visually checked for consistency and completeness.

Special attention was given to:

• Panel corners
• Rail connections
• Gate frames
• Hinge plates
• Locking component supports

Coating Inspection

The finished surface was checked for:

• Color consistency
• Visible scratches
• Exposed steel
• Powder accumulation
• Uneven coverage

Gate Assembly Check

Vehicle and pedestrian gates were temporarily assembled before packing.

This check confirmed:

• Hinge alignment
• Gate opening direction
• Frame dimensions
• Lock position
• Compatibility with gate posts

Quantity Verification

Panels, posts, gates, brackets, bolts, and spare parts were counted against the packing list before container loading.

Accessories were labeled according to the corresponding installation area.

Packaging

The tubular fence products were packed to reduce surface contact and movement during transportation.

The packaging system included:

• Steel pallets for fence panels
• Protective material between coated surfaces
• Wrapped post bundles
• Separate wooden cases for brackets and bolts
• Reinforced protection for gate corners
• Identification labels for each installation zone

Large gates were secured separately because their frame dimensions and weight required additional handling protection.

Delivery

The complete project was shipped in 11 × 40HQ containers.

BDFENCE prepared a container loading plan before shipment. Panels, posts, gates, and accessories were arranged according to installation sequence where practical.

The shipping documents included:

• Commercial invoice
• Packing list
• Container loading details
• Product identification information
• Installation reference drawings

All containers were dispatched within the agreed delivery schedule.

Installation Process

The customer’s local contractor completed the installation using the drawings and component labels supplied by BDFENCE.

The main installation stages included:

1. Surveying and marking the fence line
2. Excavating post foundations
3. Positioning and concreting the posts
4. Allowing the foundations to cure
5. Installing the tubular fence panels
6. Adjusting panel alignment
7. Installing pedestrian and vehicle gates
8. Completing the final inspection

The standard panel and post system allowed long straight sections to be installed efficiently. Customized corner and gate components reduced the need for on-site modification.

Installation Result

The completed fence created a continuous perimeter around the logistics park while preserving visibility for security patrols and surveillance cameras.

The installed system provided:

• Controlled access to warehouse areas
• Clear separation between public and restricted zones
• A consistent appearance across the entire development
• Wide vehicle access for trucks and trailers
• Durable outdoor protection with low routine maintenance

The black tubular fence also matched the external color scheme of the buildings and entrance structures.

Customer Feedback

The project contractor reported that the panels and posts were accurately manufactured and that the labeled packaging simplified material distribution across the site.

The customer was particularly satisfied with:

• Consistent panel dimensions
• Uniform powder-coated finish
• Stable gate construction
• Complete accessory quantities
• Organized shipment documentation

The availability of matching fence panels, posts, gates, and hardware from one manufacturer also reduced coordination between multiple suppliers.

Why Steel Tubular Fence Was Selected for This Project

Strong Structural Appearance

The welded tubular construction provides a rigid and professional perimeter suitable for industrial and commercial developments.

Open Visibility

The vertical rail layout allows security personnel and cameras to observe activity outside and inside the boundary.

Flexible Design Options

Panel height, rail spacing, post section, top design, gate width, and coating color can be adjusted according to the project.

Low Maintenance Requirements

The galvanized and powder-coated finish helps protect the steel structure from outdoor exposure and reduces the need for frequent repainting.

Suitable for Multiple Access Points

Steel tubular fencing can be manufactured with matching pedestrian gates, swing gates, and sliding gates, making it suitable for logistics facilities with complex traffic requirements.

Why Choose BDFENCE as Your Steel Tubular Fence Manufacturer?

Hebei Bendin Industrial Technology Co., Ltd. manufactures steel fencing systems for commercial, industrial, infrastructure, and perimeter protection projects.

BDFENCE is supported by more than 30 years of metal fence manufacturing experience and operates a 15,000㎡ production facility with more than 80 advanced machines.

Our manufacturing and export capabilities include:

• Customized fence panel production
• Matching post and bracket manufacturing
• Pedestrian and vehicle gate fabrication
• Powder-coating production
• Project-based quality inspection
• Export packaging and container loading
• Delivery support for international customers

BDFENCE has exported fencing products to more than 70 countries and can manufacture complete tubular fence systems according to project drawings and technical requirements.

Partner with BDFENCE

For logistics parks, warehouses, commercial properties, industrial facilities, residential developments, and public infrastructure projects, BDFENCE can provide customized steel tubular fence systems.

To prepare a project quotation, please provide:

• Total fence length
• Required fence height
• Panel design or reference drawing
• Post installation method
• Gate quantities and opening widths
• Preferred surface treatment and color
• Destination port or project location

FAQ

Can BDFENCE customize the spacing between vertical tubular rails?

Yes. The rail dimensions and spacing can be adjusted according to the required security level, appearance, and local project requirements.

Can steel tubular fence panels be installed on concrete walls?

Yes. Posts can be manufactured with welded base plates for installation on suitable concrete foundations or walls. Anchor specifications should be confirmed according to the supporting structure.

Can the gates use the same design as the fence panels?

Yes. Pedestrian, swing, and sliding gates can use matching tubular infill, height, color, and top design to create a consistent perimeter appearance.

Which surface treatment is suitable for outdoor tubular fencing?

Galvanized steel with polyester powder coating is commonly selected for outdoor projects. The final coating system should be chosen according to the climate, corrosion exposure, and required service life.

Does BDFENCE provide installation drawings?

Yes. BDFENCE can provide reference drawings for panels, posts, brackets, and gates to support local installation.

How is a steel tubular fence quotation calculated?

The quotation is influenced by panel height, tube dimensions, wall thickness, rail spacing, post design, gate quantities, coating requirements, order volume, packaging, and shipping destination.
