Introduction

358 Fence is one of the most widely used high-security perimeter protection systems for correctional facilities, military bases, airports, and critical infrastructure projects. With its small mesh opening, high-strength welded structure, and excellent anti-climb performance, Prison 358 Fence provides reliable security protection against unauthorized access and intrusion.

For this correctional facility project, BDFENCE supplied 18,500 sets of 358 Security Fence panels, 12,600 security fence posts, 3,200 meters of anti-climb topping system, and 16 heavy-duty security gates to establish a complete prison perimeter protection system.

The project required a fencing solution that could meet strict security requirements, maintain long-term durability in outdoor environments, and integrate with electronic perimeter monitoring systems.

PROJECT BACKGROUND

High Security Requirements For Correctional Facilities

The client required a professional Prison Perimeter Fence System to secure the boundary of a large correctional facility.

The main requirements included:

Prevent unauthorized climbing
Resist cutting attempts
Provide clear surveillance visibility
Support CCTV monitoring
Reduce long-term maintenance costs

Traditional chain link fencing could not meet the required security level, therefore a higher-performance 358 Anti Climb Fence System was selected.

Complex Security Zones

The project covered multiple security areas:

Main Prison Boundary

Required:

Maximum intrusion prevention
Strong welded mesh structure
Long service life

Vehicle Access Areas

Required:

Heavy-duty security gates
Controlled access systems
Reinforced fence structures

Internal Security Areas

Required:

Different fence heights
Additional anti-climb protection
Flexible installation solutions

OUR SOLUTION

Product: 358 High Security Anti Climb Fence System

BDFENCE provided a complete security fencing solution including:

358 Security Fence Panels

Specifications:

Mesh opening: 76.2mm × 12.7mm
Wire diameter: 4.0mm
Panel height: 2.4m–3.6m
Panel width: 2515mm
High-strength welded steel wire

The narrow mesh design prevents hands and feet from gripping the fence, creating excellent anti-climbing performance.

Security Fence Post System

The project used reinforced posts:

Features:

Heavy-duty steel posts
Anti-tamper fixing system
Concrete foundation installation
Integrated security accessories

Anti-Climb Security Enhancement

Additional security components included:

V-Type Security Extension

Used for:

Razor wire installation
Increased perimeter height
Enhanced intrusion prevention

Electric Security Integration

Fence panels were customized with:

Sensor installation space
CCTV monitoring compatibility
Perimeter alarm system integration

CUSTOMIZATION HIGHLIGHTS

High Strength Welded Structure

All fence panels used high-quality steel wire with:

Strong welding points
Uniform mesh openings
Excellent impact resistance

This structure provides better protection compared with traditional fencing systems.

Advanced Surface Treatment

To ensure long-term outdoor performance:

Hot Dip Galvanized Treatment

Features:

Zinc coating: 80-100μm
Excellent corrosion resistance
Suitable for harsh environments

Powder Coated Finish

Customized color:

RAL6005 Green

Benefits:

Better landscape integration
UV resistance
Improved appearance

Customized Fence Heights

Different prison security zones required different heights:

2.4m standard perimeter fence
3.0m high-security area fence
3.6m maximum security zone fence

QUALITY CONTROL

Raw Material Inspection

Before production:

Steel wire diameter inspection
Tensile strength testing
Zinc coating inspection

Production Process Inspection

During manufacturing:

Welding Quality Control

Checked:

Weld strength
Mesh accuracy
Panel flatness

Coating Inspection

Verified:

Coating thickness
Surface uniformity
Color consistency

Final Shipment Inspection

Before delivery:

Random panel sampling
Dimension verification
Accessories checking
Gate operation testing

All products were inspected according to international quality requirements.

PROJECT EXECUTION HIGHLIGHTS

Large Scale Manufacturing Capability

BDFENCE completed production of:

18,500 sets 358 Fence panels
12,600 fence posts
16 security gates

within the agreed production schedule.

Professional Packaging And Logistics

To protect products during international transportation:

Steel pallet packaging
Anti-scratch protection
Waterproof wrapping
Container optimization loading

were applied.

Installation Support

BDFENCE provided:

Installation drawings
Technical guidance
Fence layout suggestions
Security configuration recommendations

to ensure smooth installation at the project site.

WHY 358 FENCE IS IDEAL FOR PRISON SECURITY PROJECTS

Superior Anti-Climb Performance

The 12.7mm × 76.2mm mesh opening prevents climbing tools and handholds, making it one of the safest perimeter solutions.

Excellent Anti-Cut Protection

The welded steel structure provides strong resistance against cutting and forced entry.

Clear Security Visibility

Unlike solid barriers, 358 Fence allows:

CCTV monitoring
Security patrol observation
Better lighting conditions

Low Maintenance Cost

With galvanized and powder coating protection, the fence provides long-term outdoor durability with minimal maintenance.

CUSTOMER FEEDBACK

The correctional facility contractor commented:

“BDFENCE provided a professional high-security fencing solution that perfectly matched our prison perimeter protection requirements. The quality of the 358 Fence panels, coating performance, and customized security design were excellent. We appreciate their technical support and reliable delivery.”

PARTNER WITH A TRUSTED 358 FENCE MANUFACTURER

BDFENCE specializes in manufacturing high-security fencing systems for global projects, including:

Prison Security Fence
Airport Security Fence
Military Perimeter Fence
Data Center Security Fence
Industrial Protection Fence

With advanced production equipment, strict quality control, and customized manufacturing capability, BDFENCE provides reliable 358 Fence solutions for customers worldwide.

For your next high-security perimeter project, contact our team for professional support.

WhatsApp: +86 18703287372
Email: mazhijia18@gmail.com

FAQ

What is 358 Fence used for in prison security projects?

358 Fence is commonly used for prison perimeter protection because its small mesh opening provides excellent anti-climb and anti-cut performance.

Why is 358 Fence called Anti Climb Fence?

The 358 mesh design has very narrow openings, making it difficult for people to place hands or feet on the surface and climb over.

Is 358 Fence stronger than Chain Link Fence?

Yes. 358 Fence uses welded steel mesh panels with stronger structural performance, making it more suitable for high-security applications.

Can 358 Fence be customized for different prison security levels?

Yes. Fence height, coating, posts, gates, and additional security accessories can be customized according to project requirements.

How long does 358 Security Fence last?

With hot-dip galvanization and powder coating, 358 Security Fence can provide decades of reliable outdoor protection depending on environmental conditions.

Can BDFENCE provide complete prison perimeter fencing solutions?

Yes. BDFENCE provides complete solutions including fence panels, posts, gates, security accessories, technical drawings, and global shipping support.
